Cable Ampacity Quick Reference Chart

A compact two-page reference table of allowable current-carrying capacities for copper and aluminium cables (cross-sections 1.5–240 mm²), with correction factors for installation method, ambient temperature, and grouping.

Includes basic fuse/breaker selection guidelines. Designed for field use – print, laminate, and keep on site.

• Copper & aluminium cable ampacity tables (1.5–240 mm²)
• Correction factors: installation method, ambient temperature, grouping
• Basic fuse/breaker selection guidelines
• Print-ready, high-resolution layout
• Instant download, no subscription

Format: PDF (printable, high resolution) – 2 pages
